F4150
F4150
F4150 structural drawing
F4150
F4150 Structural Drawing
Share

Aiko 1.5 Ton Fully Automatic Pedestrian Electric Pallet Truck with 1 Battery (560 x 1150mm)

$1,550.00

F4150

Add to wishlist
SKU: F4150 Category: AIKO Lifting Equipment
  • Description
  • Reviews (0)

Description

Specification :

Drive Electric
Operator type Pedestrian
Load capacity, Q (kg) 1500
Load center distance, c (mm) 600
Load distance, centre of drive axle to fork, x (mm) 950
Wheelbase, y (mm) 1180
Service weight (kg) 120
Axle loading, laden front/rear (kg) 480/1140
Axle loading, unladen front/rear (kg) 90/30
Tyre type Polyurethane
Tyre size, front Tyre size, rear 210mm x70mm
Additional wheels (castor wheels) (mm) 80mmx60mm
Wheels, number front/rear (x=drive wheels) (mm) 74mm×30mm
Tread width, front , b₁₀ (mm) 1x. -14
Tread width, rear, b₁₁ (mm) 410 (535)
Lift height, h₃ (mm) 105
Height of tiller handle in drive position min./max., h₁₄ (mm) 750/1190
Lowered height, h₁₃ (mm) 88
Overall length, l₁ (mm) 1550
Length to face of forks, l₂ (mm) 400
Overall width, b₁ / b₂ (mm) 590 (695)
Fork dimensions, s×e×l (mm) 55X150X1150
Distance between fork-arms, b₅ (mm) 560 (685)
Ground clearance, center of wheelbase, m₂ (mm) 25
Aisle width for pallets 1000×1200 cross ways, Ast (mm) 2160
Aisle width for pallets 800×1200 lengthways, Ast (mm) 2025
Turning radius, Wa (mm) 1360
Travel speed, laden/unladen (km/h) 4/4.5
Lifting speed, laden/unladen (m/s) 0.017/0.020
Lowering speed, laden/unladen (m/s) 0.058/0.046
Max. gradeability, laden/unladen (%) Jun-16
Service brake Electromagnetic
Drive motor rating S2 60 min (kW) 0.75
Lift motor rating at S3 15% (kW) 0.5
Battery voltage/nominal capacity (V/Ah) 24/20
Battery weight (kg) 5
Energy consumption according to DIN EN 16796 (kWh/h) 0.18
Turnover output according to VDI 2198 (t/h) 60
Turnover efficiency according to VDI 2198 (t/kWh) 383.33
Type of drive control DC
Steering design Mechanical
Sound pressure level at the driver’s ear dB (A) 74
