Description
Imperial
Maximum Operating Pressure (psi) 10,000
Maximum Operating Pressure (psi) 10,000
Pressure Rating (psi) 1st Stage 500
Pressure Rating (psi) 2nd Stage 10,000
Cylinder Compatability : Single-acting
Reservoir Capacity (in3): 41
Usable Oil Capacity (in3): 41
Maximum Flow at Rated Pressure .15 in3/stroke
Oil Displacement per Stroke (in3) :1st Stage 1
Oil Displacement per Stroke (in3) : 2nd Stage 0.15
Maximum Handle Effort (lbs) 88
Piston Stroke (in) 1
Valve Operation : Manual
Power Source : Manual
Weight (lbs) 15.6
Metric
Maximum Operating Pressure (bar) 700
Pressure Rating 1st Stage (bar) 34
Pressure Rating 2nd Stage (bar) 700
Cylinder Compatability : Single-acting
Reservoir Capacity (cm3) : 672
Usable Oil Capacity (cm3) : 672
Maximum Flow at Rated Pressure : 2,46 cm3/stroke
Oil Displacement Per Stroke 1st Stage (cm3) : 16,39
Oil Displacement Per Stroke 2nd Stage (cm3) : 2,46
Maximum Handle Effort (kg) : 40
Piston Stroke (mm) : 25,4
Valve Operation : Manual
Power Source : Manual
Weight (kg) : 7,1
Dimension :
Dimension A (mm) 391
Dimension B (mm) 487
Dimension C (mm) 30
Dimension D (mm) 35
Dimension E (mm) 47
Dimension H (mm) 550
Dimension J (mm) 424
Dimension L (mm) 163
Dimension N (mm) 140
Dimension P (mm) 111
Dimension S (mm) 8,4
