Description
High efficiency cast aluminum air motor for increased life and reduced air consumption
Reinforced heavy-duty reservoir for applications in tough environments
New generation air saver piston with rugged one-piece design reduces air consumption and operating costs
Return-to-tank port for use in remote valve applications
Quiet – only 76dBA with low air consumption of 12 scfm
Operating air pressure: 40-125 psi, enables pump to start at extremely low pressure
Internal pressure relief valve provides overload protection
Specifications:
Maximum Operating Pressure (psi)10,000 or 700 bars
Cylinder Compatibility Single-acting
Reservoir Capacity (in3)127 / 2081 cm3
Maximum Flow at Rated Pressure10 in3/min /0.15 l/min
Output Flow Rate (in3/min) No Load 60 or 1 L/min
Output Flow Rate Load (in3/min)10 or 0.16 l/min
Valve Function Advance / Hold / Retract
Valve Operation Manual
Valve Type 3-way, 3-position
Power Source Air
Pump Control Hand / Foot
Air Consumption (scfm) 12 or 340L/min
Weight (lbs)18 or 8.2Kg
