Description
- Anti-bit wobbling structure
- Two ball bearings are used to securely hold the anvil for reduced bit wobbling
- Despite the internal design change for the rigidity, redesigned gear section makes the overall length 2 mm shorter than DTD155
- Compact body for easy screwdriving in narrow space
- 3-mode operation for A-mode / Hard mode / Soft mode for multiple applications
- Variable speed (0-1,300/0-3,000 RPM & 0-2,000/0-4,100 IPM)
Specifications:
- Capacity:
- Machine Screw: M4 – M8 (5/32″ – 5/16″)
- Standard Bolt: M5 – M14 (3/16 – 9/16″)
- High strength bolt : M5 – M12 (3/16″ – 1/2″)
- Coarse thread (in length): 22 – 90 mm (7/8” – 3-1/2”)
- Hex shank: 6.35mm (1/4″)
- Impacts Per Minute (IPM): Hard/Soft: 0-3,900/0-1,600
- No load speed (rpm): Hard/Soft: 0-3,000/0-1,300
- Max. fastening torque: 140 N.m
- Dimensions (L x W x H): 133 x 81 x 232 mm
- Net weight: 1.2 – 1.5 kg (2.7 – 3.3 lbs.)
