Description
Applications:
Centrifugal single impeller low head water pump for flow irrigation system with high flow rates.
Suitable to pump clean water or non -aggressive liquids charged with small solid impurities.
To be used in flow irrigation systems in gardening and agriculture or in industrial fittings.
Operation Conditions:
Max working pressure 4 bars
Liquid temperature up to 60 degree C
Ambient temperature up to 40 degree C
Total suction lift up to 8m
Continuous duty
Motor : Industrial Class B
Protection IP44
Materials:
Pump Body : Cast Iron
Motor Support : Aluminum
Impeller : Noryl
Shaft with rotor : Superior Steel
Mechanical seal : Carbon / Ceramic
Inside Thermal Protection
Specifications:
Power : 0.37 kw or 0.5hp
Inlet & Outlet : 1″ x 1″
Max Flow : 90Liter per min
Max Head : 23m
Max Suction : 8m
Gross Weight : 8.4Kg
Packaging dimension : 294 x 190 x 240mm
