Description
Features
- The body of motor and pump is made of rigid cast iron for long lasting durability.
- Greatly increase maximum submersion depth due to mechanical seal resistant to high pressure.
- Semi-open impeller made of high chrome alloy match with wear plate (ductile iron) achieves superior durability.
- Effective motor cooling due to discharge channel cast as part of the motor housing.
- Hermetically sealed motor equipped build-in thermal protection for the power below 15kW.
Applications
- Civil engineering
- Mines
- Quarries
- Coal ore
- Slurries
- Sewage treatment plants
Specifications
| Power | 3phase 2 HP |
| Maximum Capacity | 450L/min |
| Maximum Head | 22m |
| Discharge Size | 2″ (50 mm) |
| Impeller Passage | 8.5mm |
| Packaging Dimensions (H x L x W) | 590mm x 290mm x 27mm |
| Packaging Weight | 37.5kg |
| Pump Dimensions (H x L x W) | 517mm x 235mm x 216mm |
| Pump Weight | 34.5kg |
Come with 8m cable
