Description
This is a standard, inch dial indicator. It offers you the following benefits:
- Bezel clamp and lifting lever (optional) can be attached to either right or left side. They can be easily installed and removed without tools.
- No through screw holes on the frame and secure adhesion between the bezel and the crystal as well as the use of an O-ring prevents water or oil penetration.
Digital/Analog: Analog
Inch-Metric: Inch
Range: 1″
Range per rev.: 0.1″
Graduation: 0,001″
Accuracy: ±0,002″
Measuring force: 0,4-1,8 N
Error of indication one revolution: ±0,002″
Type: ANSI/AGD Standard
Stem: 9.52 mm / 0.375″
Contact point: Carbide tipped, thread: 4-48UNF
Delivered: With certificate of inspection
Continuous dial: Yes
Mass: 164 g
Functions: ANSI/AGD type
Dimensions:
| A: |
38.9 mm
|
| B: |
76.8 mm
|
| C: |
57 mm
|
| D: |
17.7 mm
|
| E: |
19 mm
|
| F: |
13.6 mm
|
| G: |
34.7 mm
|
| I: |
7.6 mm
|
