Description
The Mitutoyo 513-403-10E Horizontal Basic Set Dial Test Indicator has the following specifications:
- Range: .008″
- Graduation: .0001″
- Accuracy: +/- .0001″
- Dial reading: 0-4-0
- Measuring Force: 0.3N or less
- Contact Point Length: 19mm
- Anti-Magnet
- Jeweled Bearing
Features:
- Available in Metric, Inch and Metric/Inch models
- Crystal is glare-free with a scratch-resistant coating
- O-ring seal and bonding of the bezel and crystal protects against dust and oil while rotating smoothly
- Contact point length is printed on the dial face to avoid accuracy issues
- Newly designed contact point holder prevents backlash
- Supplied in a fitted plastic case
- Performs easy and accurate measurement of narrow or recessed areas, plus inside and outside diameters that dial indicators cannot access.
- No-clutch structure for automatic reversal of measuring direction.
- One-piece bezel and crystal design with O-ring provide resistance to water and dust.
- The glare-free flat crystal face has a scratch-resistant coating.
- High sensitivity and quick response because of jeweled bearings.
- Standard carbide contact point provide.
- Basic Set Includes: Test Indicator with .079″ Diameter Contact Point, knurled clamp ring, and 3/8″ Dovetail
- Full Set Includes: Test Indicator with .079″ Diameter Contact Point, .039″ Diameter Contact Point, .118″ Diameter Contact Point, .157″ Diameter Dovetail, Swivel Clamp, 4″ Holding Bar
The Mitutoyo 513-403-10E horizontal type dial test indicator performs easy and accurate measurement in narrow or recessed areas and provides outside diameters that dial indicators cannot access. The Mitutoyo horizontal type dial test indicator with reversible measuring direction and adjustable contact point is ideal for measuring surface variations in narrow or recessed areas with high precision. The dial test indicator’s one-piece movement provides high-impact resistance and better durability, while other optional features included jeweled bearings, anti-magnetic, long contact point, and compact versions. The horizontal face is parallel to the axis of the indicator, and the indicator can be mounted either horizontally or vertically from the front, top or back of the indicator.
