Description
Adopt Advanced IGBT Module technology of the core inverter device.
Untouch Start System– Smooth Arc-Striking with HF Control.
Continuous adjustment of cutting current.
Rapid Arc Restrike– Quality narrow cutting and excellent travel speed.
Function Post Gas for effective cooling of the cutting torch.
Competitive Cutting Thickness(Carbon Steel) – Recommended thickness: 40mm.
Cool Operation, Long Consumable Life–Cutting accessories with competitive price and performance.
Engine Drive Compatible– Wide range for input voltage,Select a suitable Engine Drive in remote locations.
Auto-Protection against Low air pressure, over-voltage, over-current and over-heated.
Energy Saving – Compared with the traditional cutting machine more efficient.
Specifications:
| Rated Input Voltage(V)：AC380V±15% 3P | Efficiency(%)：85 |
| Input Frequency (HZ)：50/60 | Power Factor：0.93 |
| Rated Input Power(KVA)：29 | Protection Grade：IP21 |
| Rated Input Current(A)：44 | Arc-Initiating：H-F,Untouch |
| Open Circuit Voltage(V)：320 | Air Pressure(MPa)：0.4-0.5 |
| Current Range(A)：20-160 | Recommend Cutting Thickness（mm）：≤50 |
| Rated Output Voltage（V）：144 | Weight(kg)：60 |
| Duty cycle at maximum current：60%@40℃ | Dimension(mm)：670*320*640 |
Standard Accessories :
1 Pcs Power Source
6M A141 gun and cable assembly
3M cable and 300A clamp
1 Set air filter kit
