Description
| Rated Input Voltage(V)：AC380V±15% 3P | Arc-Initiating(TIG)：H-F |
| Rated Input Current(A)：TIG:13.5  MMA:19.6 | Efficiency(%)：85 |
| Input Frequency (HZ)：50/60 | Power Factor：0.93 |
| Rated Input Power(KVA)：TIG:8.9  MMA:12.9 | Protection Grade：IP21 |
| Open Circuit Voltage(V)：54 | Weight(kg)：39 |
| Current Range(A)：10-315 | Dimension(mm)：616*326*620 |
| Duty cycle at maximum current：60@25℃ |
Standard Accessories :Â
- 4m TIG 26 Torch and cable assembly
- 300A stick electrode holder
- 3m cable with Plug
- 3m work cable and 300A clamp with plug
- 3m input cable without plug
