Tsurumi 4ins 7.5kW Drainage Submersible Pump

Description

Generally applicable high grade pump that can be used efficiently in draining in civil engineering through to deep well applications.
Incorporating on the job requirements in the initial product design, Tsurumi has built a powerful new series of pumps to match the demands of tough drainage jobs.

Rugged
By offering a cast iron pump body, our durability is increased over standard aluminum body pumps. Within each motor size there is a choice between high head and high volume performance ranges.
Efficient motor cooling
Slim line design with a top discharge offers economy of space. There is efficient motor cooling through a side flow channel.
Increased water-pressure resistance
A newly developed mechanical seal endures water pressure of up to 5 kgf/cm2 (0,49MPa/cm2). This has made our KTZ submersible pumps usable at greater depth, such as in deep wells, to say nothing of use at general construction sites.

Specifications:
Bore : 100mm
Motor Output : 7.5kW
Rated current Amps : 15A
Max Head : 40m
Flow Capacity : 1400 Liter per min
Dry weight : 105 Kg
Max Solid pass through : 12mm
